- Brand-new design concept
- Applicable to all sizes of manual wheelchairs | Children's wheelchairs
- Intelligent control switch | LED light | Battery display | Going upstairs | Going downstairs
- Adjustable headrest height
- Adjustable track speed and opening angle
- Adjustable pull rod height
- Front wheel full-range steering
- Non-removable IP54 lithium battery
Certifications
(EU)2017/745 | EN ISO 13485:2016
EN ISO 14971:2019 | EN ISO 20417:2021
EN ISO 15223-1:2021 | EN 62336-1:2015
EN ISO 10993-1:2020 | ISO 10993-5:2009
ISO 10993-10:2021 | ISO 10993-23:2021
IEC 60601-1:2015+AMD1:2012+AMD2:2020 CSV
IEC 60601-1-2:2014+AMD1:2020 CSV
EN 12184:2009 | ISO 7176-1:2014 and Series
Load Capacity
150KG
Adjustment Range Of Headrest ( Up | Down )
620 (mm)
Adjustment Range Of Top Holder ( Up | Down )
275 (mm)
Adjustment Range Of Top Holder ( Left | Right )
348-963 (mm)
Adjustment Range Of Top Holder ( Front | Rear )
170-230 (mm)
Adjustment Range Of Bottom Holder ( Left | Right )
519-766 (mm)
Bottom Fixture Size Parameters : Width | Length | Height
82 | 518 | 203 (mm)
Headrest Size
227*88 (mm)
Handle Telescopic Distance ( Up )
370-1030 (mm)
Handle Telescopic Distance ( Down )
520-800 (mm)
Wheel Size (F / R)
1.2” / 1.2” Inches
